POWER STAGES

18+1 power stages combine high side and low side MOSFETS and drivers into a single package, delivering power and efficiency that the latest Intel processors can take full advantage of

COOLING INNOVATION

1. Integrated I/O Cover & VRM Heatsinks
2. Thermal Pads
3. M.2 Combo-Sink
4. Two M.2 Heatsinks
5. Two M.2 Backplates

DDR5 Overclocking Strength

Comprehensive memory tuning options are the cornerstone of ROG motherboards.

For DDR5, the ROG Strix Z690 E Gaming WiFi breaks performance limits with a stacked suite of overclocking parameters for both high speed kits and entry level memory modules that have a locked power management integrated circuit (PMIC)

PCIe Performance

With one PCIe 5.0 M.2 slot delivering twice the speed of PCIe 4.0, two additional slots with PCIe 4.0, and two more 4.0 slots available on the bundled ROG Hyper M.2 Card, ROG Strix Z690 E Gaming WiFi leverages mighty CPU and chipset bandwidth to deliver the latest data transfers, Intel NVM Express RAID, and high capacity drive options that blaze past traditional SATA based SSDs

Networking

WIFI 6E (802.11 AX) Onboard WiFi 6E technology takes advantage of the newly available radio spectrum in the 6 GHz band. It provides up to three times the bandwidth of the 5 GHz band and up to seven 160 MHz bands to deliver ultrafast wireless networking speeds and improved capacity as well as better performance in dense wireless environments.

Intel 2.5 Gb Ethernet Onboard 2.5 Gb Ethernet gives your wired connection a boost, delivering up to 2.5X the speed of standard Ethernet connections for faster file transfers, low-lag gaming and high-resolution video streaming.

TWO-WAY AI NOISE CANCELATION

This powerful ASUS exclusive utility leverages a massive deep learning database to reduce background noise from the microphone* and incoming audio while preserving voices. Distracting keyboard clatter, mouse clicks and other ambient noises are removed so you can hear and be heard with perfect clarity while gaming or during calls

SUPREMEFX

ROG SupremeFX is a unique blend of hardware a nd software that provides superior audio. In ROG Strix Z690 E Gaming WiFi, SupremeFX features the ALC4080 codec to increase playback resolution from 192 kHz to 384 kHz across all channels. The front panel output is streamed through a highly integrated Savi tech amplifier that’s capable of driving of a wide variety of gaming headsets and high fidelity headphones

PCIE SLOT Q-RELEASE

A physical button unlocks the first PCIe slot’s security latch with one tap, greatly simplifying the process of detaching a PCI e card from the motherboard when it’s time to upgrade to a new GPU or other compatible device

CERTIFIED COMPATIBILITY

ROG Strix motherboards undergo an extensive certification program to ensure compatibility with the widest range of components and d evices. Our Qualified Vendor List (QVL) provides a reference for identifying guaranteed compatible components and memory
